Synergy 4134-L HD Tie Rod End Left Hand Metal | 2000-2013 Dodge RAM 2500/3500 4WD

Features:

• Fits 2000-2013 Ram 2500 and 3500 4x4
• Built for Synergy 8525 steering systems
• Heavy-duty metal-on-metal bearing design
• Greaseable joint for long service life
• Forged 1018 steel bearing housing
• 4140 steel stud with heat-treated surface
• Grease grooves improve internal lubrication flow
• Spring-loaded bearing stays tight over time
• No nylon races to wear or deform
• Larger shank eliminates base stress risers
• Low misalignment boot available separately
• Includes all required installation hardware

Fix Sloppy Steering With A Real Solution

If your front end feels loose or your steering has a dead spot that just won't go away, the Synergy 4134-L HD Tie Rod End is the kind of fix that actually lasts. Built for 2000-2013 Dodge Ram 2500 and 3500 4x4 trucks running Synergy’s 8525 steering system, this tie rod end is a serious upgrade over factory parts. It’s fully greasable and built with a metal-on-metal bearing design that holds up through years of hard use. Whether you’re towing, daily driving, or heading off-road, this part keeps your steering response tight and consistent. Unlike cheaper alternatives, it won’t loosen up over time thanks to its spring-loaded bearing setup that maintains internal pressure as it wears. Add in a larger, non-tapered shank and high-strength forged materials, and you’ve got a tie rod end you can trust. For anyone serious about eliminating weak points in their steering system, this is a no-brainer upgrade.

Built For Strength Longevity And Precision Control

The Synergy 4134-L Tie Rod End is engineered with durability and performance in mind, using a sintered metal-on-metal bushing that resists wear far better than standard nylon race designs. Its internal components are supported by a spring-loaded bearing assembly that keeps tension consistent as the joint wears, reducing slack and maintaining a positive steering feel. Grease grooves are machined into the outer surface of the ball to allow better grease flow across all contact points, extending the service life of the joint. The bearing housing is forged from 1018 steel, while the stud is made from 4140 steel with an induction heat-treated surface for smooth articulation and long-term strength. This tie rod end also features a larger-than-stock shank without a stress riser at the base, reducing the chance of fatigue-related failure. It comes with all necessary hardware and is left-hand threaded with a 1-14 UNF shank and 1.6 taper. A low misalignment boot is available separately if needed for added steering stability.

Fitment: 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013 Dodge RAM 2500/3500 4WD

Notes:

• Designed for use with Synergy 8525 steering systems
• Fits 2000-2013 Dodge Ram 2500 4x4 models
• Fits 2000-2012 Dodge Ram 3500 4x4 models
• Not compatible with factory steering components
• Left-hand thread with 1-14 UNF shank and 1.6 taper
• Low misalignment boot not included (sold separately as part 4134-02)
• Requires use of Synergy High Performance Grease (part 4119) for best results
• Includes all necessary installation hardware
• Fully greasable design requires periodic maintenance
• Not intended as a direct OEM replacement
