Oil Filter Mount Aluminum Billet

Features:

• CNC machined 6061 billet aluminum
• Black anodized corrosion resistant finish
• Higher flow than factory mount
• 360 degree adjustable port orientation
• Leak free -12 ORB ports
• Includes magnetic drain plugs
• Built in 1/8 inch NPT sensor port
• Includes two filter thread adapters
• Compatible with HP4 and HP6 filters
• Four position mounting bracket
• Supports remote oil filter relocation
• Fits PPE and GM oil filters

Give Your Engine The Oil System It Deserves

When you're building an engine for performance, towing, or long term reliability, every part of the oiling system deserves careful attention. The PPE 6061 Billet Aluminum Remote Oil Filter Mount makes relocating your oil filter simple while adding the flexibility to run larger filters and improve service accessibility. Instead of struggling to reach a factory mounted filter in a cramped engine bay, you can position the filter where routine maintenance is faster and more convenient. The high flow design also helps support engines that demand increased oil volume without creating unnecessary restrictions. Additionally, the billet aluminum construction provides the strength and durability needed for demanding street, towing, and racing environments. Whether you are upgrading an existing oil system or designing a custom setup from the ground up, this remote filter mount delivers the premium quality and versatility that serious enthusiasts expect from PPE.

Engineered For High Flow And Flexible Installation

Machined from 6061-T6 billet aluminum and finished with a durable black anodized coating, the PPE 114002100 Remote Oil Filter Mount is built to provide long lasting performance in demanding applications. The housing features one outlet and three -12 ORB inlet ports, allowing for high flow oil routing while maintaining a secure and leak free connection. Furthermore, the 360 degree adjustable inlet and outlet orientation makes hose routing easier, while the four position mounting bracket provides added flexibility when selecting an installation location. A built in 1/8 inch NPT port allows for the installation of an oil pressure or oil temperature sending unit without requiring additional adapters. Two neodymium magnet equipped plugs are included to help capture ferrous metal particles circulating in the oil, and they can be easily cleaned during routine maintenance. The mount also includes both 13/16"-16 and 1-1/2"-12 threaded filter adapters for compatibility with PPE and GM oil filters, including HP4 and HP6 racing filters, making it an excellent choice for custom oil filter relocation projects and high performance oiling systems.

Fitment: PPE Filters & GM filters Applications

Notes:

• Designed for remote oil filter relocation projects.
• Fits PPE and select GM oil filters.
• Compatible with HP4 and HP6 racing filters.
• Includes 13/16"-16 and 1-1/2"-12 adapters.
• Additional filter adapters are sold separately.
• Features one outlet and three inlet ports.
• Includes a 1/8 inch NPT sensor port.
• Mounting bracket offers four mounting positions.
• Oil lines and fittings are not included.
• Verify filter thread size before installation.
