Stage 1 Lift Kit - for 4.5" Lift

Features:

• Provides 4.5 inches of suspension lift
• Fits 2009-2012 Dodge RAM 2500/3500 4WD
• Dual rate coils improve ride quality
• Matched 2.0 Aluminum Series shocks included
• Heavy duty steel link arms included
• Increased wheel travel improves suspension performance
• Corrected steering geometry supports proper handling
• Reduces body roll compared to stock
• Clears 35 inch tires without modifications
• Maintains factory towing capacity
• No driveshaft modifications required
• Levels front and rear stance
• Made in the USA

Put More Ground Between Your Ram And The Trail

Your heavy duty Ram already knows how to work, and the ICON K214550T Stage 1 Lift Kit gives it the extra clearance and suspension control to venture farther when the road gets rough. Built for 2009-2012 Dodge Ram 2500 and 3500 4WD trucks, this system raises the suspension 4.5 inches while creating a level front to rear stance that looks right at home on a hardworking truck. ICON engineered dual rate coil springs pair with matched 2.0 Aluminum Series shocks to improve ride quality and keep suspension movement controlled through changing road conditions. Heavy duty tubular steel upper and lower links add strength while reducing the bind found in the factory link bushings, allowing the front suspension to work more effectively across uneven ground. That extra capability comes in handy on construction sites and dirt roads, yet the system is still tuned to maintain a smooth highway feel when the truck heads back to pavement. The added clearance also makes room for 35 inch tires without modifications, giving you an easy path toward a larger tire setup and more confident stance. Better yet, towing capacity remains unchanged and no driveshaft modifications are needed, so you can add meaningful suspension capability without taking away from the everyday usefulness of your Ram.

The Right Geometry Makes Lift Height More Useful

ICON builds the K214550T as a complete suspension system rather than relying on taller springs alone to achieve the desired 4.5 inch ride height. Dual rate front coil springs work alongside polyurethane bumpstops with billet extensions and sway bar drop brackets to support the increased suspension travel. A forged drop pitman arm and track bar drop bracket reposition important steering and axle locating components, helping maintain proper geometry as the suspension moves through compression and droop. Tubular steel upper and lower link arms increase strength and alignment range while reducing the binding associated with the original link bushings. Matched 2.0 Aluminum Series smooth body shocks are used at the front and rear, and their fully serviceable construction provides an option for future maintenance as mileage accumulates. The rear suspension uses 2.5 inch lift blocks and extended U bolts to complement the front ride height while preserving the intended level stance. Additionally, the system supports factory wheels and tires, while ICON recommends a 35 by 12.50 tire when moving to an aftermarket setup. Together, these components create a coordinated suspension package focused on proper geometry, usable wheel travel, and balanced road manners after lifting your Ram.

Fitment: 2009, 2010, 2011, 2012 Dodge RAM 2500/3500 4WD w/ 4.5" Lift

Notes:

• Fits 2009-2012 RAM 2500/3500 4WD models
• Springs are rated for diesel engines only
• OEM wheels and tires are compatible
• Recommended tire size is 35x12.50
• Larger tires may require fender trimming
• Adjustable track bar may be needed
• No driveshaft modifications are required
• Factory towing capacity remains unchanged
• Shocks are fully serviceable
• Lift height assumes a stock equipped vehicle
• Contact ICON for 2013 Ram applications
• Kit ships in multiple boxes
• Product images may be representative
