BDS FOX88326100 FOX 2.5 PES DSC Rear Shocks - 4-6 inch Lift | 2017-2025 Ford F250/F350 Super Duty 4WD

BDS FOX88326100 FOX 2.5 PES DSC Rear Shocks - 4-6 inch Lift | 2017-2025 Ford F250/F350 Super Duty 4WD

Manufacturer: BDS Suspension

SKU: BDSFOX88326100
Price
$1,699.95
Ships From Manufacturer in 1-3 Days
American Express
Apple Pay
Diners Club
Discover
Google Pay
Mastercard
PayPal
Shop Pay
Venmo
Visa

Features:

  • Fits 4–6 inch lifted Super Duty trucks
  • Designed for 2017–2025 F250/F350 4WD
  • 2.5" aluminum body resists rust and corrosion
  • DSC adjusters control low and high-speed compression
  • Race-developed high-flow piston for better control
  • External reservoir improves cooling and performance
  • 6061-T6 aluminum components are CNC machined
  • 7/8" heat-treated chrome plated shock shaft
  • PTFE-lined spherical bearings for smooth articulation
  • Redundant sealing system prevents fluid contamination
  • Hard-anodized finish provides long-lasting durability
  • Built to match BDS lift system geometry

Performance Elite Series 2.5 Reservoir smooth body shocks give you enhanced ride quality and the control you need when heading off the pavement. They take their design from our Off-Road race shocks, so they've been thoroughly perfected in brutal conditions that you will probably never see. Our athletes push the boundaries in competition to develop race-proven performance you can bolt onto your Truck or SUV. The external reservoir allows for increased oil and nitrogen capacity while delivering a striking race look. Applications are available to fit most stock and lifted Trucks and SUVs. Our complete line of bolt-on, Performance Elite shocks provide improved damping in any terrain. Experience for yourself the incredible performance and precise control that Performance Elite Series 2.5 Reservoir shocks deliver.


Body 2.5" impact extruded and CNC machined 6061-T6 hard anodized aluminum body resists rust over time
Body Plating Hard-anodized for a durable finish
Reservoir External reservoir design separates shock oil from the high-pressure nitrogen
Components Black-anodized, CNC-machined 6061-T6 billet aluminum
Shaft 7/8" hard chrome plated heat-treated alloy steel
Piston Race-developed high-flow piston design
Valving Application specific valving to maximize performance
Seals Redundant sealing pack system main seal, wiper seal, scraper seal
Bearing PTFE-lined, heat-treated, alloy steel spherical
Adjuster Type DSC - Dual Speed Compression
Extended 34.930
Compressed 21.350
Travel 13.580
Top Mount Eyelet
Bottom Mount Eyelet



Vehicle Fitment: 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025 Ford F-250/F-350 Super Duty 4WD

BDS Kits: This kit is intended for use with BDS lift systems and is generally not ordered by itself as several other components are required to make a complete BDS lift kit.

Year Ranges Make Model Series Engine
2017-2025 Ford Super Duty F250/F350 6.7L Powerstroke
Property Values
Year Ranges 2017-2025
Make Ford
Model Super Duty
Series F250/F350
Engine 6.7L Powerstroke
