D37 6" inch Coil Spring Lift Kit - 4" inch Rear Axle

Features:

• Fits 2009-2013 RAM 2500 6.7L 4WD
• 6 inch front coil spring lift
• 4 inch rear lift blocks
• Clears up to 37 inch tires
• 100 percent bolt on installation
• No cutting or welding required
• High strength control arm brackets
• Track bar relocation bracket included
• Dropped pitman arm for steering correction
• Transfer case indexing ring included
• Powdercoated components for durability
• Brake line brackets included

Stand Taller And Clear The Tires You Have Always Wanted

If you are ready to give your 2009-2013 RAM 2500 6.7L Cummins a serious presence on the road, the Zone Offroad D37 6 inch Lift Kit delivers the height and attitude to match. This system lifts the front 6 inches with coil springs and raises the rear 4 inches, creating a bold stance that easily clears up to 37 inch tires. The result is a truck that looks right at home on aggressive 17, 18, or 20 inch wheels with the proper backspacing. Additionally, the 100 percent bolt on design means you can achieve this transformation without cutting or welding the frame. Everything is engineered to work together, so you get the look you want along with dependable on road handling. Whether you are building a weekend showpiece or a trail ready diesel, this kit helps your RAM stand out from the crowd in a big way.

Engineered Geometry Corrections For A Properly Lifted Cummins

The D37 kit is designed specifically for 2009-2013 RAM 2500 4WD diesel models with a 4 inch rear axle and 4 link front suspension. High strength control arm relocation brackets are included to correct suspension geometry and maintain proper alignment after the 6 inch front lift. A track bar relocation bracket and dropped pitman arm help keep steering angles in check, which is critical for stable highway driving. Furthermore, rear lift blocks and U bolts provide the 4 inch rear height while maintaining factory leaf spring positioning. Brake line brackets are supplied to ensure adequate slack at full suspension travel. The included transfer case indexing ring helps address potential driveline angles, and additional solutions are available for two piece rear driveshaft applications if needed. Finished in durable powdercoat and shipped with all necessary hardware, this kit is built to provide a complete and well thought out lift solution without unnecessary fabrication.

Fitment:

• 2009, 2010, 2011, 2012, 2013 Dodge Ram 2500/3500 4WD/Diesel with 4" rear axle

Quick Specs:

• Front Lift Height: 6"
• Rear Lift Height: 4"
• Front Lift Method: Coil Springs
• Rear Lift Method: Cast Blocks
• Lift Type: Lift Kit
• Wheel Size: 17 x 9
• Back Spacing: 5"
• Max Tire Size: 37 x 12.5
• Wheel Size 2: 18 x 9
• Back Spacing 2: 5"
• Max Tire Size 2: 37 x 12.5
• Wheel Size 3: 20 x 9
• Back Spacing 3: 5"
• Max Tire Size 3: 37 x 12.5
• Finish: Powdercoat
• Cutting Required: No
• Accommodates Factory Wheels: See Notes
• Welding Required: No

Important Notes:

• Check Rear Axle Diameter: This truck was produced using rear axles of differing diameters; measure the diameter of your rear axle to ensure proper kit selection in configuration.
• Driveline Notice: Although rare, if you experience front driveline vibration, install the optional transfer case indexing ring.
• Fitment: This kit is not designed for dually models, but may me easily adapted to accommodate your truck. Please contact customer support and they will help you find a solution.
• Gas models may require modification to the front exhaust crossover pipe on driver side when using the transfer case indexing ring.
• Two-piece rear drive shaft? Add a carrier bearing drop kit to reduce post-lift driveline angles and avoid / eliminate driveshaft vibration.
• Wheels / Tires: Adding larger-than-stock wheels? Add front bumper spacers to your kit for additional clearance as some wheel / tire combos may not fully clear the bumper’s stock location.
• Works on 2013 2500 with 4 link front suspension only. Will not fit 1 Ton Trucks.

In the Box:

• All Necessary Mounting / Installation Hardware
• Brake Line Brackets
• Coil Springs
• Control Arm Relocation Brackets
• Dropped Pitman Arm
• Rear Lift Block & U-Bolt Kit
• Track Bar Relocation Bracket
• Transfer Case Indexing Ring
