2" inch R2 Pintop Lift System

Features:

• Front & Rear Performance Shocks
• External remote reservoirs
• Premium Front & Rear Leveling Coils
• Front & Rear Bump Stop Drops
• Overall 2" lift
• Adjustable Track bar
• Levels Out Vehicle Stance
• Great for on and off-road
• Enhanced Ride and Performance Quality
• Limited Lifetime Warranty

High-Quality Pintop Lift Kit for Ram 2500

If you want to give your 2014-2018 Dodge Ram 2500 a major upgrade in both performance and appeal, check out the Carli 2" R2 Pintop Lift System! This premium aftermarket suspension lift kit includes everything you'll need to acheive a more commanding view of the road, improved off-road performance, and a boost in exterior style in a simple and effective package. Each kit comes equipped with Carli's Premium 3" Linear Rate Front Coil Springs that prop your truck's front-end, giving you improved ground clearance over uneven terrain while helping to accommodate for larger tire/wheel combinations. In the rear, you'll find 2" Heavy-Duty Multi Rate Coil Springs that provide a leveled stance for your ride, and are capable of of handling a constant payload. You'll also receive a full set of front and rear Carli Tuned King 2.5 RR Performance shocks which are much more durable over the Backcountry System's shocks, providing impressive damping characteristics while delivering improved handling and stability when you're behind the wheel. Each shock comes equipped with an external remote reservoir that allows for a greater volume of shock oil, providing faster heat dissipation when you're out pushing things to the limit. This kit also helps out during any towing/hauling applications as it works to keep you in control even when your ride is under a heavy load.

Additional Suspension Modifications

Along with it's major performance benefits, the Carli Pintop Lift System comes equipped with an adjustable track bar that works to reduce body roll and sway when you head well off the beaten path. Pair this track bar with the included front and rear bump stop drops and your truck will be ready to take on any adventure you have in mind. The bump stop drops help correct your truck's suspension geometry to maintain maximum wheel travel, reducing a ton of stress on various suspension components. Radius arm drop brackets allow for corrected suspension geometry, allowing you to maximize your drive quality over both on and off-road terrain. These components work to keep your truck stable and in control even when you're out pushing things to the limit.

Fitment:

• 2014, 2015, 2016, 2017, 2018 Dodge Ram 2500 PowerWagon 4WD
• Not compatible with models equipped with Rear Air Suspension

Base Kit Includes: Carli Tuned King 2.5 RR Front & Rear Shocks, Front & Rear Multi Rate Coil Springs, Extended Sway Bar End Links, Front & Rear Bump Stop Drops, Radius Arm Drop, Adjustable Track Bar, Track Bar Drop Bracket, Reservoir Mounts, Brake Tabs.

Wheel Recommendations: This system will fit up to a 37" Tire when utilizing wheels that are no more than 9" with 5.75"-6" of backspacing. An 18" diameter wheel will allow for optimal ride quality.
