BDS 1828FPE 3 inch FOX 2.5 Elite Coilover Lift Kit | 2020-2025 GM 2500HD/3500HD 6.6L Duramax w/ Rear Overload

Features:

• 3-inch suspension lift height
• FOX 2.5 Performance Elite coilovers
• Remote reservoirs for cooler shock temps
• DSC adjusters for compression control

• Heavy duty upper control arms
• Boxed gusseted lower control arms
• Increased suspension travel and articulation
• Maintains ride quality with factory overload
• Rear block kit included
• Clearance for up to 35-inch tires
• 100 percent bolt-on installation

Upgrade How Your Truck Feels and Performs

If your Heavy Duty feels more like a brick than a beast, the BDS 1828FPE 3-inch FOX 2.5 Coilover Lift Kit is the upgrade it’s been waiting for. This isn’t just about adding height—it’s about unlocking real performance and capability from front to rear. You’ll immediately notice a more stable ride on the road, along with a smoother, more controlled feel when navigating off-pavement. FOX’s 2.5 Performance Elite coilovers soak up rough terrain like it's nothing, and with DSC compression adjusters, you can fine-tune the ride to match your driving style. It’s the kind of suspension that gives you confidence when towing, hauling, or just heading out on a weekend trail run. Plus, it opens up clearance for 35-inch tires, giving your truck the aggressive stance and off-road readiness it was built for. Whether you're looking for comfort, capability, or just a better feel behind the wheel, this kit delivers where it counts!

Engineered for Strength Travel and Tunability

Beneath the surface, this BDS lift kit is packed with serious hardware built to handle demanding conditions. Up front, FOX 2.5 Performance Elite coilovers with remote reservoirs and dual-speed compression adjusters offer increased travel and precise damping control. The coilovers bolt directly into place, replacing the factory torsion bar system with a more efficient and tunable setup. To handle the increased suspension movement, BDS includes TIG-welded upper control arms made from 1.5-inch OD tubing, along with fully boxed and gusseted lower control arms, built from high-strength steel. Out back, the kit includes a rear lift block designed specifically for trucks with factory overload springs, maintaining load capacity while improving stance. Rounding it out are FOX 2.5 Performance Elite rear shocks tuned for a balance of comfort and off-road control, completing a system that’s as refined as it is rugged.

Fits: 2020, 2021, 2022, 2023, 2024, 2025 GM 2500HD/3500HD 6.6L Duramax w/ Rear Overload

Note:

• Models with two-piece rear drive shafts require a carrier bearing drop kit (BDS121612)
• Requires frame bracket modification and minor welding
• Factory torsion bar system requires a special unloading tool
• GM specified tool number is CH48809
• Compatible with diesel models only, including standard and AT4 trims
• Not recommended for gas models due to excessive lift
• Available preload adjustment may not achieve correct ride height on gas models
• Minor trimming may be needed with certain wheel and tire combinations
• Trimming typically involves inner fender shrouds or bumper valance corners
• Deeper backspacing and narrower tires reduce trimming requirements
• Dually models require aftermarket 20" wheels with max 285/60/20 tires
• Factory 17", 18", and 20" wheels cannot be reused due to control arm clearance
• Coilover coil has high preload and requires a spring compressor for removal
• Failure to use a spring compressor may result in serious injury or death
• Do not increase coilover preload
• Use service kit BDS081203 for replacement ball joints
• Ball joints must be installed with the dot facing inward or outward
• Track width increases 1" per side for improved droop travel and clearance

Wheel and Tire Fitment:

• 35 x 12.50 on 17" x 9" with 4.5 to 5.5" backspacing**
• 285/75 on 17" x 9" with 4.5 to 5.5" backspacing*
• 35 x 12.50 on 18" x 9" with 4.5 to 5.5" backspacing**
• 285/70 on 18" x 9" with 4.5 to 5.5" backspacing*
• 35 x 12.50 on 20" x 9" with 4.5 to 5.5" backspacing**
• 295/60 on 20" x 9" with 4.5 to 5.5" backspacing*
• For wheels larger than 20", use 20" wheel specs
• **Trimming is required
• *Trimming may be required
• Stock 17", 18", and 20" wheels will not fit after installation
