Front 7" inch Box Kit

Features:

• Essential for ICON 7 inch lift systems
• Fits 2011-2016 Ford F250/F350 Super Duty 4WD
• Corrects track bar angle and axle placement
• Helps eliminate steering bump steer
• Corrects steering geometry after lifting
• Includes 4 inch drop pitman arm
• Prevents sway bar binding
• Retains stock replacement steering stabilizer compatibility
• Reuses factory brake lines
• CNC machined aluminum bump stop spacers
• Heavy duty quarter inch steel bracket
• Fully bolt on installation
• Installation hardware included

Build Your Seven Inch Lift On Better Geometry

Getting your Super Duty seven inches higher is the obvious part of the upgrade, but making sure the steering and suspension still work together is where the ICON 67030 Front Box Kit earns its place. Designed for 2011-2016 Ford F250 and F350 Super Duty 4WD trucks, this package supplies essential supporting components for an ICON 7 inch lift suspension system. The included track bar bracket and 4 inch drop pitman arm address the geometry changes that come with added ride height, helping keep the front axle properly positioned while reducing unwanted bump steer. ICON also accounts for sway bar movement with drop brackets that help prevent binding as the suspension works through its full range of travel. Brake line drop brackets let you reuse the factory brake lines, which keeps the installation cleaner and avoids an unnecessary brake line upgrade. A dedicated steering stabilizer bracket maintains compatibility with a stock replacement stabilizer, while aluminum bump stop spacers help complete the lifted suspension configuration. It is the kind of package that handles the less glamorous details of a big lift so your truck can feel properly sorted once it is back on the ground.

Critical Components Keep The Front End In Sync

The ICON 67030 Front Box Kit is engineered to correct several suspension and steering relationships affected by an ICON 7 inch lift on 2011-2016 Ford Super Duty 4WD models. Its front track bar drop bracket is CNC laser cut and brake formed from .25 inch steel plate to provide a strong mounting point while correcting track bar angle and axle placement. The included 4 inch drop pitman arm adjusts steering geometry so the drag link and track bar maintain the relationship needed to help eliminate bump steer. A fabricated steering stabilizer drop bracket works with this corrected geometry and allows fitment of a stock replacement steering stabilizer shock at the drag link. Front sway bar drop brackets reposition the sway bar to prevent link binding throughout suspension travel, while CNC machined aluminum bump stop spacers support proper suspension operation. Brake line drop brackets provide the additional positioning needed to reuse the stock brake lines, simplifying the installation and reducing the need for additional components. All required installation hardware is included, while the fabricated parts receive a corrosion resistant semi gloss black powder coat finish and are backed by ICON's Limited Lifetime Warranty.

Fitment: 2011, 2012, 2013, 2014, 2015, 2016 Ford F250/F350 Super Duty 4WD w/ 7" Front Lift

Notes:

• Fits 2011-2016 Ford F250/F350 Super Duty 4WD models.
• Designed specifically for ICON 7" lift systems.
• This is a supporting component kit.
• Includes a 4" drop pitman arm.
• Includes a front track bar drop bracket.
• Includes front sway bar drop brackets.
• Includes a steering stabilizer drop bracket.
• Includes brake line drop brackets.
• Factory brake lines can be reused.
• Supports stock replacement steering stabilizer fitment.
• Installation hardware is included.
• California residents should review Proposition 65 warnings.

• Product images may be representative.
