B8 5160 Rear Shock - for 0–0.5" Lift - (Single)

Features:

• Supports 0–0.5" rear lift
• Fits 2014–2026 RAM 2500 4WD trucks
• Remote reservoir increases oil capacity
• Improves heat dissipation under heavy use
• Digressive valving reacts to terrain changes
• Monotube gas design prevents shock fade
• 360° swivel banjo hose fitting for easy routing
• Triple-C coating resists corrosion and wear
• Floating piston allows increased wheel travel
• Ideal for off-road and heavy-duty use
• Direct bolt-on installation, no mods required
• Sold individually, order two for rear setup

Lift Your Rig And Get More Dampening

Bilstein B8 5160 Series stock-mount remote reservoir shocks feature the company's industry-leading monotube design, with a reservoir mounting configuration specifically designed for each application. Their unique digressive valving system instantly produces full damping capabilities for serious off-road performance and control. The remote reservoir dramatically increases shock oil capacity for excellent heat dissipation and damping sensitivity. A floating dividing piston is located in the reservoir of these shocks to offer increased wheel travel and more shaft movement. Special swivel banjo fittings on the reservoir hose allow for 360 degrees of rotation. Bilstein's exclusive Triple-C Technology finish provides the B8 5160 Series shocks with lasting great looks and easy care.

Fitment: 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026 RAM 2500 4WD w/ 0–0.5" rear lift

Specs:

• Extended Length: 25.71
• Collapsed Length: 17.17
• Internal Design: Monotube
• Adjustable Valving: No
• Gas Charged: Yes
• Boot Included: No
• Body Diameter (in.):1.811
• Quantity: Sold Individually

Notes:

• Only fits 2014–2026 Ram 2500 4WD with 0–0.5" rear lift
• Not compatible with rear air suspension systems
• Designed for trucks at or near stock ride height
• Ideal for off-road use, towing, and loaded driving
• Remote reservoir improves shock cooling and longevity
• Monotube design ensures consistent performance under stress
• Floating piston in reservoir increases shaft travel range
• Swivel banjo hose fitting allows clean, flexible routing
• Triple-C coating protects against corrosion and rust
• Pre-tuned digressive valving enhances control and comfort
• Shock mounts with standard eyelet-to-eyelet configuration
• Sold individually, purchase two for both rear positions
• Product images may be representative
