B8 5100 Rear Shock - for 2-4" Lift - (Single)

Features:

• Supports 2-4" rear lift
• Premium rear shock absorber
• Gas-charged monotube design
• Consistent damping performance
• 46mm digressive piston
• Offers 12" of travel
• Zinc-plated finish
• Maintains factory ride quality
• Straightforward installation
• Sold Individually

Improves Rear Suspension Performance

The factory rear shocks on your 1999-2016 Ford F250/F350 start to reach their limitations after adding a lift/leveling kit or larger wheels and tires to your rig. This happens because the OEM shocks weren't designed to handle anything more than basic street driving and the occasional load, and a new suspension system causes additional stress onto the shocks. In order to achieve premium on and off-road performance, pick up the Bilstein B8 5100 Series Rear Shock Absorber. This aftermarket rear shock was built from the ground up and designed for moderate to heavy-duty applications, ensuring your Super Duty will be ready for just about anything you throw at it. Specialized valving and the high-quality piston provides excellent off-road performance, improved towing control, and a much more pleasant street ride without compromise.

Premium Construction & Installation Info

The Bilstein B8 5100 Series Rear Shock Absorber was built around a monotube, nitrogen gas chamber design with a massive 46mm digressive piston that separates the shock oil from the high-pressure nitrogen for consistent damping performance over every terrain. Moreover, each shock uses self-adjusting deflective disc valving that provides you with excellent responsiveness in any situation. The body of the shock is made from durable steel and then paired with a zinc-plated finish and Triple-C coating for an impressive appeal while helping to combat the damaging effects of rust and corrosion. When it comes to installation, these shocks were designed for a direct, drop-in replacement of your stock components to make for a quick and easy process you can complete at home.

Fitment: 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016 Ford F-250/F-350 (Rear Lifted 2-4")

Notes:

• Fits 1999-2016 Ford F250 and F350 Super Duty models.
• Designed for trucks with 2 to 4 inches of lift.
• Verify your rear lift height before ordering.
• Sold individually. Order two for a complete rear replacement.
• Direct fit using factory-style mounting locations.
• Application-specific valving is tuned for lifted Super Duty trucks.
• Non-adjustable damping requires no post-install tuning.
• Upper mount uses a 16mm eye. Lower mount uses a 12mm eye.
• Includes a protective black bellows boot.
• No reservoir or spring seat is included.
• Ideal for towing, hauling, and off-road driving.
• Backed by Bilstein's limited lifetime warranty.
• Product images may be representative.
