62 Gallon High-Capacity Fuel Tank

Features:

• Massive 62-gallon fuel capacity
• Replaces factory 26-gallon fuel tank
• No cutting or drilling required
• Includes premium S&B sending unit
• Aftermarket lift pump ready
• Venturi jet pump prevents quarter-tank issues
• Gooseneck and fifth-wheel compatible
• Built-in sump for added versatility
• Transfer pump ready design
• Includes heavy-duty mounting straps
• Convenient integrated drain
• Midship design maintains practical placement

Spend More Time Driving And Less Time Fueling

If your Duramax spends long days towing, traveling, or working far from the next fuel stop, the S&B 10-1006-1 62 Gallon High Capacity Fuel Tank gives you the extra range to make those miles easier to manage. Designed for 2004-2010 GM Silverado and Sierra 2500HD and 3500HD 6.6L Duramax Crew Cab Short Bed trucks, this tank replaces the factory 26 gallon tank with approximately 62 gallons of onboard capacity. That huge increase means fewer fuel stops and more flexibility when planning long hauls, especially when pulling a gooseneck or fifth wheel since the tank is compatible with both setups. S&B also gives you 10 more gallons of capacity than competing replacement tanks, making better use of the available space underneath your truck. Installation is straightforward because the tank replaces the original without requiring cutting, drilling, or special modifications, and the necessary mounting straps are included. Additionally, the tank is ready for aftermarket lift pumps and transfer pumps, giving you room to build a fuel system that better suits the way you use your Duramax. For owners who rely on their truck to cover serious distance, this 62 gallon upgrade delivers the kind of added range and everyday convenience that quickly becomes difficult to give up.

Purpose Built Fuel Capacity For Your Duramax

The S&B 10-1006-1 is more than a larger fuel container because its components are designed to work with the fuel system on compatible 2004-2010 GM Duramax trucks. Its midship tank measures 79.25 by 17.74 by 20.82 inches and includes an S&B OEM style sending unit for a clean connection with factory fuel systems. The sending unit incorporates S&B venturi jet pump technology, which addresses common quarter tank fuel delivery issues that can occur when running aftermarket lift pumps. What's more, the tank includes a sump, a drain, and an embedded fitting with a 1/2 inch NPT thread, giving owners useful provisions for different fuel system configurations. The larger bottom surface area also creates a greater fuel reserve when the low fuel indicator activates compared with the original tank. Buyers should keep in mind that the tank sits approximately 5 inches lower than the original fuel tank and is not compatible with the factory skid plate. GM's distance to empty calculation cannot be recalibrated for the additional capacity, so the displayed remaining mileage will be approximately half of the truck's actual available range, while high flow truck stop nozzles will require manual filling rather than automatic operation.

Fitment: 2004, 2005, 2006, 2007, 2008, 2009, 2010 GM Silverado/Sierra 2500HD/3500HD 6.6L Duramax Crew Cab/Short Bed

Notes:

• Fits Crew Cab Short Bed applications only
• Replaces the factory 26 gallon fuel tank
• Tank sits approximately 5 inches lower
• Not compatible with the factory skid plate
• Distance to empty cannot be recalibrated
• DTE may show about half remaining range
• High flow nozzles will not auto shutoff
• Low fuel light leaves greater reserve
• Compatible with gooseneck and fifth wheel setups
• Aftermarket lift pump compatible
• Transfer pump ready
• California Prop 65 warning applies
• Product images may be representative
